Lukas Compact Units - Manual (Page 33)

33
Trouble Cause Solution
Fluid leaks from the
hydraulic fluid reservoir
(especially from the filler
screw)
Due to hydraulic fluid
returning from the
implement, the maximum
capacity of the tank is
exceeded
Reduce the level in the
hydraulic fluid reservoir to
the mark on the dipstick or
inspection glass
Defective seal Have repaired by
authorised dealer or
directly by LUKAS
Leaking fluid between
engine and flange bearing
Radial shaft seal on the
drive shaft is defective
Have repaired by
authorised dealer or
directly by LUKAS
Hydraulic fluid milky and
cloudy
Water / condensation in
the system
Immediately replace
hydraulic fluid
With quick-disconnect
coupling system: hose
assembly cannot be
coupled
Pressurised Switch the control unit to
depressurised circulation
Defective hydraulic
coupling
Hydraulic coupling needs
to be replaced immediately
With quick-disconnect
coupling system: Leak in
the coupling (male)
Safety valve reacted After pressure release,
there is no more leakage.
Defective hydraulic
coupling
Hydraulic coupling nipple
needs to be replaced
immediately
With quick-disconnect
coupling system: Leak in
the coupling (female)
Defective hydraulic
coupling
Hydraulic coupling sleeve
needs to be replaced
immediately
Hydraulic fluid leak on the
hoses or the connections
Leak, possible damage Replace hoses
Damage on the surface of
the hydraulic hoses
Mechanical damage or
contact with aggressive
agents
Replace hoses
If it is not possible to rectify the malfunctions, inform an authorised LUKAS dealer or the
LUKAS Customer Service department immediately.
The address of the LUKAS Customer Service Department is:
LUKAS
Hydraulik GmbH
Weinstraße 39, D-91058 Erlangen
Postfach 2560, D-91013 Erlangen
Tel.: (+49) 09131 / 698 - 348
Fax.: (+49) 09131 / 698 - 353
