Chapter 3

Making a Good Thing Better

To install a PCI Express card:

Open your Mac Pro and remove the side panel, following the instructions in “Opening
Your Mac Pro” on page 33.

WARNING:

To avoid damaging internal components or the components you want to

install, always turn off and then unplug your Mac Pro. Do not attempt to install items
while it is plugged in. Let your Mac Pro cool down for 5 to 10 minutes before you
touch the internal components, which may be very hot.

Unscrew the captive screws in the PCI bracket and remove the bracket.

Port access cover

PCI bracket

Remove the port access cover from the slot in which you plan to install the card.
