IMPORTANT APPLICATION SPECIFIC SETTINGS
Infinity Tuner Wizard Setup
Engine
In the Wizard Engine tab confirm the following settings:
Number of Cylinders
= 4
Engine Cycle Type
= 4 Stroke
Ignition Type
= Distributor
Firing Order
= 1-3-4-2
Cam/Crank
In the Wizard Cam/Crank tab confirm the following setting:
Honda Distributor (1992–2000)
Add a text grid control to your layout and select the following channels. Make sure their values match
the settings below for initial timing sync. These values will be populated when the Cam/Crank pattern is
selected.
TrigOffset [degBTDC]
= 35.00
CamSyncAdjustment
= 8.00
Injector Setup
In the Wizard Injector Setup tab confirm the following setting:
Number of Injectors = 4
Input Functions
In the Wizard Input Function Assignment tab confirm the following setting:
AC Request Switch Setup = Digital6
Ignition Sync
See QuickStart Guide section Setup: Ignition Sync for instructions on timing sync.
