Creating Labels Efficiently 18
Introduc
tion
Crea
ting La
be
ls (F
or
Wind
ows)
C
re
at
ing
L
a
be
ls (
F
or
M
ac
int
os
h)
Ap
pe
nd
ix
„ Creating and registering a new Layout Style
When there is no layout style appropriate for the label you want to create, you can create a new layout style.
You can then save it as a new layout style for later use.
1
Click [File]-[New].
The [New] dialog box appears.
2
Click [New Layout], and click .
3
Create a text object and adjust its position
or format.
4
Right-click on the created text object and
select [Properties] from the menu
displayed.
The [Text Properties] dialog box appears.
5
Click the [Expanded] tab and check the
[Change Data in Layout Style Template]
check box.
Select [Label List] in [Target], select a field
(such as [Title]) map from the label list,
and click
.
6
Repeat Steps 4 and 5 for every text object you have created.
The [Text Properties] dialog box also
appears when you double-click the created
text object.
