SkyTrak 6042 Operation Manual - Manual (Page 83)

Operation
81 Model 6042 Origin 2/04
3 Foot Truss Boom w/Winch Capacity Chart
15 21
28.4
10°
0°
D
C
B
A
E
0 ft 8 12 16 20 24 4 28
12
20
24
28
32
36
40
0 ft
8
44
WITH SKY TRAK APPROVED
TRUSS BOOM WINCH ONLY
4110375
6042
-3.1
68.4°
60°
50°
40°
30°
20°
16
ALWAYS
• travel slowly
• rig properly
• use two tethers
SWINGING LOADS can
cause MACHINE TIPOVER
which can result in death
or serious injury.
SAFETY INSTRUCTIONS
Use only with vehicles
equipped with auxiliary
hydraulics.
Always connect couplers.
ASME B56.6 - 2002 PART lll
-8°
OA1680
