SkyTrak 6042 Operation Manual - Manual (Page 147)

General Maintenance
145 Model 6042 Origin 2/04
B. Rear Axle
1. Working through the level plug hole (1), carefully use a screwdriver
to spread the brake discs apart.
IMPORTANT! DO NOT damage the surfaces of the brake discs when
spreading the brake discs.
2. Using a feeler gauge, check the gap (2) between the brake discs
(3). If the gap is greater than .167" (4,25 mm), replace the brake
discs.
NOTE: If the brake discs are worn beyond .167" (4,25 mm), the brake disc
must be replaced on both sides of the axle at the same time.
3. Repeat steps 1 and 2 for the other side of the axle.
4. Continue with step 6 of “B. Axle Oil Change” on page 141.
MT2840
2
3
