Section 9 - Specifications
9-7
31200352
Maximum Travel Speed ....................................................................20 mph (32 kph)
Towing Capacity
6036 & 6042 ............................................................................. 6,000 lb (2722 kg)
8042.......................................................................................... 8,000 lb (3629 kg)
10042 & 10054 ....................................................................... 10,000 lb (4536 kg)
Frame Leveling.......................................................................................... 10 degrees
Maximum Travel Grade
Gradeability .............................................................................. 24 degrees (45%)
Side Slope ............................................................................... 5 degrees (8.75%)
Dimensions
Overall Height
6036...........................................................................................100 in (2540 mm)
6042...........................................................................................102 in (2591 mm)
8042..........................................................................................99.4 in (2525 mm)
10042 & 10054 .......................................................................100.1 in (2543 mm)
Overall Width
6036 & 6042 ................................................................................99 in (2515 mm)
8042........................................................................................99.25 in (2521 mm)
10042 & 10054 ..........................................................................102 in (2591 mm)
Track Width
6036, 6042 & 8042 ......................................................................84 in (2134 mm)
10042 & 10054 .........................................................................84.3 in (2141 mm)
Wheelbase
6036 & 6042 .............................................................................. 113 in (2870 mm)
8042, 10042 & 10054 ............................................................. 119.5 in (3035 mm)
Overall Length (less Forks)
6036...........................................................................................217 in (5512 mm)
6042...........................................................................................220 in (5588 mm)
8042 & 10042 .........................................................................222.3 in (5646 mm)
10054......................................................................................238.8 in (6066 mm)
Ground Clearance
6036 & 6042 ..................................................................................16 in (406 mm)
8042............................................................................................17.3 in (439 mm)
10042 & 10054 ..............................................................................18 in (457 mm)
Outside Turning Radius
6036...........................................................................................165 in (4191 mm)
