Section 7 - Lubrication and Maintenance
7-12
31200352
7.5
OPERATOR MAINTENANCE INSTRUCTIONS
Fuel System
A. Fuel Level Check
1. Check fuel gauge (1) located on instrument cluster in cab.
2. If fuel is low, proceed to fuel source and perform “Shut-Down Procedure” on
3. Locate fuel tank (2), turn fuel tank cap (3) and remove from filler neck.
4. Add diesel fuel as needed.
5. Replace and secure fuel tank cap.
Note: Replenish diesel fuel at end of each work shift to minimize condensation.
NOTICE
EQUIPMENT DAMAGE. Do not allow machine to run out of fuel during operation.
See Engine Operation & Maintenance Manual for details prior to servicing.
10
OW0970
OW0990
OH4191
P
0000 00
P
1
2
3
VIEW OF FUEL TANK
FROM TOP OF MACHINE
