36
6 Examples (NEEDS REWORK)
6.1 Remote Phase Noise Measurement (FW 1.0)
Following the SCPI command sequence for a typical remote phase noise measurement.
Binary format of list
Example: 0x 23 32 3132 0050C347 7 9689A48 00247449
0x 23 : ASCII code for # -> start
0x 32 : ASCII code for 2 -> n=2
0x 3132 : ASCII code for 1 (0x31) and 2 (0x32) -> N=12 (3x 32bit float values)
0x 0050C347 : 32bit float -> 100000.0
0x 79689A48 : 32bit float -> 316227.78125
0x 00247449 : 32bit float -> 1000000.
// configuration
> CONF:RESE ON // reconfigure device before every measurement
> CONF:MEAT:IT // number of iterations
> CONF:MEAS:PPD 150 // number of points per decade
> CONF:FREQ:STAR 100 // start offset frequency 100Hz
> CONF:FREQ:STOP 1E6 // stop offset frequency 1MHz
> CONF:PN:METH CC // cross correlation mode
> CONF:PN:LOOP:AUTO ON // choose best loop bandwidth for locking
> CONF:ATT:AUTO ON // find best attenuation setting
> CONF:MODE PN // measure phase noise
> CONF:FREQ 100E6 // DUT frequency 100MHz
> *OPC? // wait for configuration to complete
< read opc status // returns 1 once the configuration is complete
// measurement
> SENS:PN:INIT // start measurement
> *OPC? // wait for measurement to complete
< read opc status // returns 1 once the measurement is complete
> SENS:PN:INIT? // was the measurement successful?
< read init status // 0: success, <0: failed
> CALC:PN:FREQ? // get offset frequency points
< read list // binary format of list explained below
> CALC:PN:SPEC? // get measurement
< read list // binary format of list explained below
