:CALCulate:REQuest:DATA

:CALCulate:AVErage:CURRent?

:CALCulate:FREQuency?

This command reads out the internal frequency counter and returns the detected DUT frequency.

:CALCulate:POWer?

This command reads out the internal power meter and returns the detected DUT power.

:CALCulate:XX:SPOT?

This command returns single spot noise value, for the active trace.

:CALCulate:PN:TRACe:FREQuqncy?

This command returns the list of offset frequency points in Hz of the phase noise measurement.

:CALCulate:PN:TRACe:SPECtrum?

This command returns the list of spectrum points in dBc/Hz. The format is similar to the query

CALC:PN:FREQuency?

:CALCulate:BB:TRACe:NOIse?

This command returns the list of noise power spectrum in dBV/Hz. The format is similar to the query

CALC:PN:FREQuency?

:CALCulate:XX:TRACe:SPURious:FREQuency?

This command returns spurious data array, for the active trace.

:CALCulate:PN:TRACe:AVARiance?

This command gets Allan Variance (data trace), for the active trace of the selected channel.

:CALCulate:PN:TRACe:INTegral?

Gets trace data integral noise, for the active trace of the selected channel.

:CALCulate:PN:TRACe:JITter?

Gets trace data total RMS jitter, for the active trace of the selected channel.

5.3 :INITiate Subsystem
