Windshield Light Mount System - Kit 87024
Mount Lights
1. Install Lights.
a. Install your desired lightings.
(Note: Not all lights may directly fit. Predrilled holes in kit
center light mount bracket may be used as a referance
and modified or enlarged to fit your lights purchased.
Engine Compartment
1. Connect both battery cables. Connect positive cable
first, then negative cable.
Install Lights or
LED Light Bar
Positive Cable
Negative Cable
Miscellaneous
1. Check all fasteners to ensure they are tight.
PARTS LIST
Qty.
Description
1
Bracket, Center Light Mount
1
Bracket, Dvr. Light Mount
1
Bracket, Psg. Light Mount
1
ZH87024 (Hardware bag kit)
6
Bolt, 3/8” x 1” Button Head
6
Nut, Flange 3/8”
6
Washer, 3/8” USS
WARNING
Retorque all fasteners after 500 miles and after off road
use. All body lift components should be visually
inspected and fasteners retorqued during routine vehi-
cle servicing.
NOTE
All warranty information, instruction sheets, and other
documents regarding the installation of this product
must be retained by the vehicle owner. Information
contained in the instructions and on the warranty card
will be required for any warranty claims. The vehicle
owner needs to understand the modifications made to
the vehicle and how they affect vehicle handling and
performance. Failure to provide the customer with this
information can result in damage to the vehicle and
severe personal injury.
