53 CAFS Bottled-Air Operator/s Guide
p/n: 029-0020-85-0
Pr es et C alib ra tio n / O p er atio n
❑
6. Begin discharging CAFS in accordance with departmental or locality
regulations. If you are satisfied with the results, continue with Step 8. to
store the setting.
7. Use the OPEN and CLOSE buttons on the smart-switch to change the
CAFS consistency to the desired WETNESS (press OPEN for WET-
TER; press CLOSE for DRYER consistency).
8. Once the required consistency is achieved, press and HOLD the WET
button for about ten (10) seconds to store (program) this new Preset 2
setting. RELEASE the button when the smart-switch flashes once.
To calibrate a DRY consistency...
1. Energize the apparatus to provide power to the operator’s panel.
2. Supply water to engage and operate the pump at an appropriate dis-
charge pressure.
3. Set the CAFSAttack ENABLE switch to the ON (I) position. Also see
Figure 2-3: “CAFSAttack Operator Control Panel” on page 21.
❑ The background indicator lights on the smart-switch controllers illumi-
nate. (See Figure 5-1: “Smart-Switch Calibration Overview,” on page
51.)
❑ The intelli-tank air level display illuminates to show the air-remaining
level in the cylinders. (See Figure 2-3: “CAFSAttack Operator Control
Panel,” on page 21.)
Note: The air level indicator lights are an accumulation of both cylinders. See
separate manual, located at the back of this manual, for additional information.
4. Set the air bottle valve handle to the OPEN (I) position. Also see Figure
2-3: “CAFSAttack Operator Control Panel” on page 21.
5. Press and release the DRY Button.
❑ The DRY button LED flashes.
❑ The valve position bar graph indicator LEDs illuminate to indicate the
relative position of the discharge valve (the less bars illuminated indi-
cates a DRYER consistency).
❑ The FoamLogix display controller is activated in preparation to flow
foam when water flow is detected.
