17
PARTS FOR BLOWER AREA
15
Parts for BLOWER AREA
ITEM QTY. P/N DESCRIPTION
1 1 51157 PULLEY, 1GRV 3.0PD AK32H, 3.25 ″ DIA.
2 1 48855 WELDMENT, BRG BRACKET PS540G
3 22 220373 SCREW, HH 3/8 ″ - 16 × 1″ SS T
3A A/R 17110-0017 NEVER SEIZE LUBRICANT - USED ON ITEMS 3 & 7
APPLIED TO THREADS BEFORE REINSTALLING
4 A/R A11039 SPLIT LOCK WASHER 3/8 ″ ZP
5 A/R 21416-0001 FLAT WASHER 3/8 ″ SS
6 2 22072-0025 BEARING, PILLOW BLOCK 5/8 ″
7 8 21326-0002 SCREW, HX HD GRS 3/8 ″ - 16 × 5-1/2″
8 6 2000203 SCREW ,HX W/HD 10 - 32 × 3/8 ″ ZC
9 1 48872 BACK WALL SHROUD
10 1 48803 AIR INLET RING
11 8 35900-0108 FAN ORIFICE STAND OFF TUBE
12 1 50643 FAN DRIVE SHAFT
13 1 21651-0010 KEY, SQ 3/16 ″ Ч 3/16″ Ч 1.00″ STL
14 1 48862 AXIAL FAN, 14 ″ DIAMETER
15 1 51110 INR/OTR BACK WELDMENT
16 1 50222 SPECIAL BUSHING, 5/8 ″ ID - 3/16″ × 3/32″ KEY
17 2 35323 COUPLING, COLLAR SPLIT 5/8 ″ DIAMETER
18 4 50271 ROLL PIN, PLN 5/32 ″ Ч 7/16″
