Bryant 569J User Manual
Page 7
7
Table 2A — Physical Data — 569J*12-14D/E Units — 60 Hz English
UNIT SIZE 569J
*12D/E
*14D/E
NOMINAL CAPACITY (tons)
10
12.5
OPERATING WEIGHTS (lb)
NOVATION™ Coil (Al Tube)
499
505
Round Tube/Plate Fin Coil (Cu/Al)
516
654
REFRIGERANT TYPE
‡
R-410A
NOVATION Operating Charge A/B, Typical (lb)
†
7.4 / 7.3
10.8 / 10.9
NOVATION Shipping Charge A/B (lb)
3.0 / 3.0
3.5 / 3.5
RTPF Operating Charge A/B, Typical (lb)
†
11.0 / 11.0
23.0/23.0
RTPF Shipping Charge A/B (lb)
8.0 / 8.0
17.0/17.0
COMPRESSOR
Qty...Type
2...Scroll
2...Scroll
Oil Charge A/B (oz)
42
60
CONDENSER FANS
Qty...Rpm
2...1100
Motor Hp
1
/
4
Diameter
22
Nominal Airflow (Cfm Total)
6000
Watts (Total)
610
RTPF CONDENSER COIL
Material (Tube/Fin)
Cu / Al
Coil Type
3
/
8
---in RTPF
Rows/Fins per inch (FPI)
2 / 17
3 / 17
Face Area (sq ft total)
25.0
31.8
NOVATION CONDENSER COIL
Material (Tube/Fin)
Al / Al
Coil Type
Novation
Rows/Fins per inch (FPI)
1 / 17
Face Area (sq ft total)
25.0
31.8
CONTROLS
Pressurestat Settings (psig)
High Cutout
630 ± 10
Cut-in
505 ± 20
Low Cutout
54 ± 3
Cut-in
117 ± 5
PIPING CONNECTIONS (in. ODS)
Qty...Suction A/B
1...1
1
/
8
/ 1...1
1
/
8
1...1
3
/
8
/ 1...1
3
/
8
Qty...Liquid A/B
1...
3
/
8
/ 1...
3
/
8
1...
1
/
2
/ 1...
1
/
2
LEGEND
RTPF — Round Tube/Plate Fin
ODS — Outside Diameter Sweat (socket)
‡
Unit is factory-supplied with partial charge only.
†
Typical operating charge with 25 ft of interconnecting piping.
