Bryant 569J - Manual (Page 22)

22
Table 10 – Electrical Data — 569J*07--14A/B 60 Hz Units
WTIHOUT POWERED CONVENIENCE OUTLET
UNIT V---Ph---Hz
VOLTAGE
RANGE }
COMPRESSOR 1 OFM (ea)
POWER
SUPPLY
MIN MAX RLA LRA WATTS FLA MCA MOCP
569J*07A/B
208/230---3---60 187 253 19 123 325 1.5 26.7 40
460---3---60 414 506 9.7 62 325 0.8 13.7 20
575---3---60 518 633 7.4 50 325 0.6 10.4 15
569J*08A/B
208/230---3---60 187 253 25 164 325 1.5 34.2 50
460---3---60 414 506 12.2 100 325 0.8 16.8 25
575---3---60 518 633 9.0 78 325 0.6 12.4 20
569J*12A/B
208/230---3---60 187 253 30.1 225 325 1.5 40.6 60
460---3---60 414 506 16.7 114 325 0.8 22.5 40
575---3---60 518 633 12.2 80 325 0.6 16.4 30
569J*14A/B
208/230---3---60 187 253 48.1 245 325 1.5 63.1 100
460---3---60 414 506 18.6 125 325 0.8 24.8 40
575---3---60 518 633 14.7 100 325 0.6 19.6 30
WTIH POWERED CONVENIENCE OUTLET
UNIT V---Ph---Hz
VOLTAGE
RANGE }
COMPRESSOR 1 OFM (ea)
POWER
SUPPLY
MIN MAX RLA LRA WATTS FLA MCA MOCP
569J*07A/B
208/230---3---60 187 253 19 123 325 1.5 31.5 45
460---3---60 414 506 9.7 62 325 0.8 15.9 25
575---3---60 518 633 7.4 50 325 0.6 12.1 20
569J*08A/B
208/230---3---60 187 253 25 164 325 1.5 39.0 50
460---3---60 414 506 12.2 100 325 0.8 19.0 30
575---3---60 518 633 9.0 78 325 0.6 18.5 30
569J*12A/B
208/230---3---60 187 253 30.1 225 325 1.5 45.4 60
460---3---60 414 506 16.7 114 325 0.8 24.7 40
575---3---60 518 633 12.2 80 325 0.6 18.1 30
569J*14A/B
208/230---3---60 187 253 48.1 245 325 1.5 67.9 100
460---3---60 414 506 18.6 125 325 0.8 27.0 40
575---3---60 518 633 14.7 100 325 0.6 21.3 30
NOTE: See “Legend and Notes for Tables 10 and 11” on page 23.
569J
