Brocade ICX 6650 Hardware Installation Guide 49
53-1002599-01
Power supply specifications
A
Power supply specifications
All units ship with two RPS15 redundant, load sharing, and hot swappable power supplies.The
power supplies are universal and capable of functioning worldwide without voltage jumpers or
switches. They meet IEC 61000-4-5 surge voltage requirements and are autoranging in terms of
accommodating input voltages and line frequencies.
Table 6 lists the power state definitions for the Brocade ICX 6650.
Table 6 lists the power supply specifications for the Brocade ICX 6650.
Inrush current should be limited to 35A peak for any initial current surge or spike of 10ms or less at
either cold or warm start. Any additional inrush current surges or spikes in the form of AC cycles or
multiple AC cycles greater than 10ms and less than 150ms must not exceed 25A peak. After
150ms the AC input current will be less than the rating of input fuses and the other components
within the power supply.
General specifications
Table 7 lists the general specifications for the Brocade ICX 6650.
TABLE 5 Power state definitions
Power State Definition
Idle All ports down, no optics or cables connected.
Typical 56x10 GbE, 4x40 GbE, and 4x4x10 GbE ports linked
and UP. 10% traffic with 64-byte packets. Fans at normal
speed.
Maximum All ports connected with optics to draw maximum power
per MSA Optics Specification. Traffic at full rate or 100%
throughput. Fans at full speed.
TABLE 6 System power specifications
AC Voltage Input Watts BTU’s/hr Power State
120 VAC 114.6 391.14 Idle
120 VAC 154.6 527.66 Typical
120 VAC 230 785.01 Maximum
TABLE 7 General specifications
Specification Description
System architecture Nonblocking shared-memory switch
System processor 800 MHz PowerPC
Switch bandwidth 1600 Gbps
Forwarding bandwidth (data rate, full
duplex) 1190 Mpps
