Brocade ICX 6650 rear panel LEDs
4
Brocade ICX 6650 rear panel LEDs
The Brocade ICX 6650 has the following LEDs on the rear panel:
• Six 40 GbE QSFP+ port status LEDs (green).
• One DIAG LED bicolor status LED (green and amber).
• Two Management port status LEDs
Figure 15 shows the LEDs on the rear panel of the Brocade ICX 6650.
FIGURE 15 Brocade ICX 6650 rear panel LEDs and port number
1 Mini-USB connector console port 2 Management port status LEDs
3 40 GbE ports 4 Ethernet management port
5 40 GbE port status LEDs
3 1
4 5
2
