a TXV, the subcooling method must be used. Heat pumps must be
operating in the cooling mode. To charge by superheat, a service
technician
needs an accurate superheat thermocouple or
thermistor-type thermometer, a sling psychrometer, and a gage
manifold. Do not use mercury or small-dial-type thermometers as
they are not adequate for this type of measurement. Then use 1 of
the following procedures:
SUPERHEAT CHARGING METHOD
1. Operate a unit a minimum of 10 minutes before checking
charge.
2. Measure vapor pressure by attaching a gage to vapor
valve-service port.
3. Measure vapor-line temperature by attaching a service
thermometer to unit vapor line near vapor valve. On a heat
pump, attach to the suction tube between the accumulator
and the compressor. Insulate thermometer for accurate
readings.
4. Measure outdoor-air, dry-bulb temperature with a second
thermometer.
5. Measure indoor-air (entering indoor coil), wet-bulb tem-
perature with a sling psychrometer.
6. Locate outdoor temperature and evaporator entering air
wet-bulb temperature in Table 21. At this intersection note
the superheat.
7. Locate superheat temperature located in previous step and
vapor pressure in Table 22. At this intersection note
vapor-line temperature.
8. If unit has a higher vapor-line temperature than charted
temperature, add refrigerant until charted temperature is
reached.
9. If unit has a lower vapor-line temperature than charted
temperature, bleed refrigerant until charted temperature is
reached.
10. If outdoor-air temperature or pressure at vapor valve
changes, charge to new vapor-line temperature indicated on
chart.
SUBCOOLING CHARGING METHOD
1. Operate unit a minimum of 15 minutes before checking
charge.
TABLE 21—SUPERHEAT CHARGING TABLE
OUTDOOR TEMP (°F)
INDOOR COIL ENTERING AIR TEMP (°F WET BULB)
50 52 54 56 58 60 62 64 66 68 70 72 74 76
55 9 12 14 17 20 23 26 29 32 35 37 40 42 45
60 7 10 12 15 18 21 24 27 30 33 35 38 40 43
65 — 6 10 13 16 19 21 24 27 30 33 36 38 41
70 — — 7 10 13 16 19 21 24 27 30 33 36 39
75 — — — 6 9 12 15 18 21 24 28 31 34 37
80 — — — — 5 8 12 15 18 21 25 28 31 35
85 — — — — — — 8 11 15 19 22 26 30 33
90 — — — — — — 5 9 13 16 20 24 27 31
95 — — — — — — — 6 10 14 18 22 25 29
100 — — — — — — — — 8 12 15 20 23 27
105 — — — — — — — — 5 9 13 17 22 26
110 — — — — — — — — — 6 11 15 20 25
115 — — — — — — — — — — 8 14 18 23
Where a dash appears, do not attempt to charge system under these conditions or refrigerant slugging may occur.
TABLE 22—REQUIRED VAPOR TEMPERATURE (°F)
SUPERHEAT TEMP
(°F)
VAPOR PRESSURE AT SERVICE PORT (PSIG)
61.5 64.2 67.1 70.0 73.0 76.0 79.2 82.4 85.7
0 35 37 39 41 43 45 47 49 51
2 37 39 41 43 45 47 49 51 53
4 39 41 43 45 47 49 51 53 55
6 41 43 45 47 49 51 53 55 57
8 43 45 47 49 51 53 55 57 59
10 45 47 49 51 53 55 57 59 61
12 47 49 51 53 55 57 59 61 63
14 49 51 53 55 57 59 61 63 65
16 51 53 55 57 59 61 63 65 67
18 53 55 57 59 61 63 65 67 69
20 55 57 59 61 63 65 67 69 71
22 57 59 61 63 65 67 69 71 73
24 59 61 63 65 67 69 71 73 75
26 61 63 65 67 69 71 73 75 77
28 63 65 67 69 71 73 75 77 79
30 65 67 69 71 73 75 77 79 81
32 67 69 71 73 75 77 79 81 83
34 69 71 73 75 77 79 81 83 85
36 71 73 75 77 79 81 83 85 87
38 73 75 77 79 81 83 85 87 89
40 75 77 79 81 83 85 87 89 91
—44—
