APPENDICES
Appendix–3
English
PARALLEL INTERFACE SPECIFICATION
Interface Connector Printer Side: Amphenol 57RE-4036-7308 or equivalent
A shielded cable should be used.
Pin Assignment
Pin No. Signal Direction Pin No. Signal Direction
1
DATA STROBE
Input 19 0V (S.G.) –
2 DATA 1 Input 20 0V (S.G.) –
3 DATA 2 Input 21 0V (S.G.) –
4 DATA 3 Input 22 0V (S.G.) –
5 DATA 4 Input 23 0V (S.G.) –
6 DATA 5 Input 24 0V (S.G.) –
7 DATA 6 Input 25 0V (S.G.) –
8 DATA 7 Input 26 0V (S.G.) –
9 DATA 8 Input 27 0V (S.G.) –
10
ACKNLG
Output 28 0V (S.G.) –
11 BUSY Output 29 0V (S.G.) –
12 PE Output 30 0V (S.G.) –
13 SLCT Output 31
INPUT PRIME
Input
14
AUTO FEED
Input 32
FAULT
Output
15 N.C. – 33 N.C. –
16 0V (S.G.) – 34 N.C. –
17 0V (S.G.) – 35 N.C. –
18 +5V – 36
SLCT IN
Input
✒ Note
To use bi-directional communication, an interface cable which has the pin
connection above should be used.
