Brother 580C - Manual (Page 130)

126
HARDWARE
Input device: KEYBOARD - 63 keys
LCD 112 x 32 dots
19 indicators
Print tape Pressure-sensitive, adhesive-based
5 widths available:
1/4” (6 mm)
3/8” (9 mm)
1/2“ (12 mm)
3/4” (18 mm)
1” (24 mm)
Power supply: 6 AA alkaline batteries
(optional AC adaptor model AD-30)
Auto power off not key if pressed within 5 minutes
or if the machine is not used for 10 minutes during
Interface mode.
Print head: 128 dot / 180 dpi
Dimensions: 8 1/2” x 8 1/2” x 2 2/3”(215 x 215 x 68 mm)
Weight: 2 lbs 3 oz (1 kg)
SOFTWARE
Character size: 6 sizes (6, 10, 13, 19, 26, and 38 points) + AUTO
All are available in NARROW, MEDIUM and WIDE
Character fonts: 8 built-in typefaces
Buffer size: Single line - 1 m
Multi-line
Multi-block
Memory size: 3,400 characters
Number of characters: 247 characters
Print styles: Normal, Bold, Outline, Solid, Shadow and Outline +
Shadow, Striped (all can be combined with Italic)
