121
ERROR MESSAGE CAUSE REMEDY
CUT NOW
•
This message appears after
a label has been printed with
the Cut pause mode on or
before multi-color printing if
the end of the tape is incorrectly
positioned.
•
Press the tape cutter lever to
cut the tape.
EJECT CUT TAPE &
PRESS RETURN
•
This message appears when
the tape has been cut, but it
not removed.
•
Remove the cut excess tape
and press RETURN key.
ERROR!
•
This message appears if you
try printing in Interface mode
without installing the correct
tape cassette.
•
Press any key other then tape
CODE, SHIFT, ALT or CAPS
keys, then install the correct
tape cassette.
ERROR! UL/FRM •
A maximum of 25 characters
can be underlined or framed.
This message appears if you
try to underline or frame more
then 25 characters.
•
Reduce the number of char-
acters that are underlined or
framed.
FIXED SIZE! •
This message appears if the
RETURN key is pressed when
a TITLE font is selected.
•
This message appears if a 1/4”
(6-mm)- or 3/8” (9-mm)- wide
tape is installed when text is
entered using a TITLE font.
•
This message appears if the
character size is changed when
a TITLE font is selected.
•
Change the font.
•
Insert a tape cassette that is
wide enough for TITLE font
text to be printed on it.
•
Since the size is fixed, do not
change it.
INPUT ABCD AT
BEING & END
•
This message appears when
the CODABAR protocol is used
in Bar code mode, but a letter
between A and B has not been
entered at the beginning and end
of the bar code.
•
Enter a letter between A and
D at the beginning and end
of the bar code.
INPUT WHOLE CODE
•
In Bar code mode, the number
of digits required for a code can
sometimes be set.
This message appears if the set
number of digits are not entered
while inputting the bar code data.
•
Input the correct number of
digits or change the number
of digits set in the bar code
parameters.
