Neff B15P52N3GB - Manual (Page 25)

25
Detaching the door
1. Open the oven door fully.
2. Fold up the two locking levers on the left and right (figure A).
3. Close the oven door as far as the limit stop. With both hands,
grip the door on the left and right-hand sides. Close the door
a little further and pull it out (figure B).
Attaching the door
Reattach the oven door in the reverse sequence to removal.
1. When attaching the oven door, ensure that both hinges are
inserted straight into the opening (figure A).
2. The notch on the hinge must engage on both sides (figure B).
3. Fold back both locking levers (figure C). Close the oven
door.
:
Risk of injury!
If the oven door falls out accidentally or a hinge snaps shut, do
not reach into the hinge. Call the after­sales service.
Removing the door cover
The oven door cover can become discoloured. To carry out
thorough cleaning, you can remove the cover.
1. Open the oven door fully.
2. Unscrew the oven door cover. To do this, undo the left and
right screws (figure A).
3. Remove the cover (figure B).
Make sure that the oven door is not closed while the cover is
removed. The inner panel may be damaged.
Clean the cover with a stainless-steel cleaning agent.
4. Replace the cover and secure it in position.
5. Close the oven door.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels from the
oven door.
When removing the inner panels, pay attention to the sequence
in which the panels are removed. In order to reassemble the
panels in the correct sequence, use the numbers that appear
on each panel.
Removal
1. Detach the oven door and lay it on a cloth with the handle
facing down.
2. Unscrew the cover at the top of the oven door. To do this,
unscrew the left and right screws (fig. A).
3. Lift the top panel up and pull it out and remove the two small
seals (fig. B).
4. Unscrew the retaining clips on the right and left. Lift the panel
and remove the clips from the panel (fig. C).
5. Remove the seal from the bottom of the panel (fig. D). Pull
the seal and remove it up and out. Pull out the panel.
6. Pull the lower panel at an angle, upwards and out.
% $
% $
&
% $
% $
' &
