8. Image Menu
There are 6 different preset color temperatures:
• Projector white
• computer : 9300 K
• Video : 6500 K
• Film : 5400 K
• Broadcast : 3200 K
• Custom Preset value
The first 5 calibrated presets can be selected and will provide optimum color tracking, the projector allows however the setting of a
personal preset color temperature, this is done in Custom Preset. Next to that Custom Preset a Custom value, which is only valid
for that moment, can be set in Custom.
Projector white will provide maximum projector light output.
Difference between Custom Preset and Custom
A Custom Preset color temperature is any color temperature set by the user and saved for later use. This value can be recalled in
the same way as a calibrated value.
Custom is used when the user wants to use a variation on a calibrated color temperature. This custom setting remains available
until another preset is selected which will overwrite the current custom values.
How to select a preset color temperature ?
1. Press MENU to activate the menu bar.
2. Press → to select the Image item. (image 8-21)
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select Color temperature.
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select the desired preset color temperature.
7. Press ENTER to confirm.
The color temperature of the image is adapted and a white bullet shows the active setting in the menu bar.
Image 8-21
How to store a customer created color temperature on Custom Preset?
1. Press MENU to activate the menu bar.
2. Press → to select the Image item. (image 8-22)
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select Color temperature.
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select Custom Preset.
R5976816 RLM R6+ PERFORMER 02/06/2006 75
