3-46 User’s Manual
PORTÉGÉ M750
TOSHIBA Express Port Replicator
The TOSHIBA Express Port Replicator connects directly to the docking
interface on the underside of the computer. The AC adaptor connects the
TOSHIBA Express Port Replicator to a power source.
The following ports are available on the TOSHIBA Express Port Replicator.
■ RJ45 LAN jack
■ External monitor port
■ DC IN 15V jack
■ Security lock slot
■ Universal Serial Bus 2.0 port (four)
■ DVI port
The computer must be configured properly before connecting to a LAN.
Logging onto a LAN using the computer’s default settings could cause a
malfunction in LAN operation. Check with your LAN administrator
regarding set-up procedures
.
■ You must connect the AC adaptor before you connect to a TOSHIBA
Express Port Replicator.
■ When a TOSHIBA Express Port Replicator is connected to the
computer, you can not use the following computer’s ports: LAN jack,
DC IN 15V jack and External monitor port.
■ When connecting an AC Adaptor to the TOSHIBA Express Port
Replicator, use only the AC Adaptor included with TOSHIBA Express
Port Replicator. Do not use the computer’s AC Adaptor.
■ As the port operation of all DVI (Digital Visual Interface) monitors has
not been confirmed, some DVI monitors may not function properly.
■ Set the TOSHIBA Express Port Replicator’s Slide Adjuster to SLIDE
position #4 when connecting this computer to the TOSHIBA Express
Port Replicator. Refer to the TOSHIBA Express Port Replicator User’s
Manual for more details on connection methods.
