3-28 User’s Manual
PORTÉGÉ M750
9. Remove the two screws and take off the memory module cover.
Figure 3-10 Removing the memory module cover
10. Align the notch of the memory module with that of the memory module
slot and gently insert the module into the slot at about a 45 degree
angle before holding it down until the latches on either side snap into
place.
Figure 3-11 Installing the memory module
Use a point size 1 Phillips screwdriver.
Memory module cover
Screws
Slot A
■ Never allow metal objects, such as screws, staples and paper clips, to
enter the computer or keyboard. Foreign metal objects can create a
short circuit, which can cause computer damage and fire, possibly
resulting in serious injury.
■ Do not touch the connectors on the memory module or on the
computer. Debris on the connectors may cause memory access
problems.
■ The memory module cover will be hot after using the computer for long
periods of time. Exercise caution when removing.
