Toshiba Portege M750 User Manual
Page 87
User’s Manual
3-37
PORTÉGÉ M750
Figure 3-20 Removing the hard disk drive pack
■
Be sure that you grasp the hard disk drive pack by its edges when you
remove/install the hard disk drive pack.
■
Do not pull the connector cables when you remove/install the hard disk
drive pack.
Hard disk drive pack
Connector
Plastic tab
a
Hard disk drive pack
Connector
Hard disk drive pack
c
b
