74
En
06 Use Other Equipment With Your Flat Panel Display
6.9.2 Assign a Baud Rate
This section describes how to enter the RS-232C transmission speed (baud rate) when controlling or adjusting
the panel using a PC. (Use this option only when making picture adjustments for a specific device(s) connected
to the RS-232C terminal.) The baud rate can be set to 1200bps, 2400bps, 4800bps, 9600bps, 19200bps or
38400bps. To enter a rate, follow the directions below.
1 ) Access Serial Setting through the Control Setup menu.
2 ) Select Baud Rate from the Serial Setting menu.
3 ) Select the desired rate from the submenu.
The factory default setting is 9600bps.
Note: This setting applies to all input sources.
6.10 Select the Integrator Mode
Integrator Mode provides alternative options when using specific functions/settings and picture adjustment
menus.
Notes: Integrator Mode is only available in English.
After entering the Integrator Mode, the following options on the Home Menu are reset to the factory
defaults:
• Picture
• Screen
After entering the Integrator Mode, the following options remain unchanged:
• Sound
• Power Control
• Option
• Input Setup
• Control Setup
To switch to the Integrator Mode, follow the directions below.
1 ) Press INPUT to select the desired input.
2 ) Press DISPLAY to reveal current settings.
Status information on the selected input appears on screen.
1200bps
2400bps
4800bps
9600bps
19200bps
38400bps
Baud Rate
- - -
FULL
Standard
Component
INPUT2
