Fax Driver
1-5
Overview
1
1.3
Setting up the system
In order to use this printing system, it must first be set up.
Setup consists of connecting this machine to a computer and installing the fax driver onto the computer
being used.
!
Detail
This manual describes the setup method of network connection only for Port9100 that will be installed
by the installer, and LPR/Port9100 that will be installed by Add Printer Wizard printing.
For installation procedures via other network connections, refer to the User’s Guide [Print Operations].
1.3.1
Network connection
1
Connect this machine to a computer.
2
Make sure the computer is connected to the network.
3
Specify the IP address of the machine to connect it to the network.
–
For details on IP address and network settings of the machine, refer to the User’s Guide [Network
Administrator].
4
Depending on the connection method and protocol, change the network settings of this machine.
–
LPR: Enable the LPD settings on the TCP/IP Setting screen.
–
Port9100: Enable the RAW port setting on the TCP/IP Setting screen, and specify the RAW port
number (default setting is "9100").
–
SMB: Enable "Print Setting" on the SMB Setting screen.
–
IPP/IPPS: Enable IPP print on the IPP Setting screen.
5
Install the fax driver.
–
Specify the network port of the fax driver according to the connection method and protocol.
1.3.2
Local connection
1
Connect this machine to a computer
2
Install the fax driver.
!
Detail
For details on connecting this machine to a computer, refer to the User’s Guide [Print Operations].
To update an existing fax driver, delete the existing fax driver first. For details, refer to
.
