About the Control Panel
30
About the Control Panel
The control panel, located on the top of the printer, allows you to direct the
printer’s operation. In addition, it displays the current status of the printer,
including any condition that needs your attention.
Control Panel Indicators and Keys
No.
Indicator
Off
On
1
The printer is not ready
to accept data.
The printer is ready to
accept data.
(Flashes while data is
being received or while
printing.)
2
No problem.
The printer requires
operator attention.
(usually accompanied by
a status message in the
message window.)
YMCK
MENU
4
1
5
6
3
8
2
7
MESSAGE
WINDOW
