Front panel
This topic provides information to help you locate the control, connectors, and LEDs on the front panel of
the server.
The following illustration shows the control, connectors, and LEDs on the front panel of the server.
Note: Depending on the model, your server might look slightly different from the following illustration.
Figure 4. Front panel
1 Power button with power status LED 4 Front USB 3.0 connector 1
2 Hard-disk-drive status LED 5 Front USB 3.0 connector 2
3 Network Interface Controller (NIC) status LED
1 Power button with power status LED
Press the power button to turn on the server when you finish setting up the server. You also can hold the
power button for several seconds to turn off the server if you cannot turn off the server from the operating
system. See Chapter 4 “Turning on and turning off the server” on page 45. The power status LED helps you
to determine the current power status.
