7. Remove the four screws

at the rear of the chassis that secure the power supply assembly, and

then push the power supply assembly from the rear until it is released from the metal retaining tab

Then, carefully lift it out of the chassis.

Figure 93. Removing the non-hot-swap power supply assembly

8. Touch the static-protective package that contains the new power supply assembly to any unpainted

surface on the outside of the server. Then, remove the new power supply assembly from the package
and ensure that the new power supply assembly is the correct replacement. See “Features” on page 7
for information about the supported power supply assembly.
