Table 18-1.
Electrical Characteristics – Voltage/Current Sources (IASG
x
Sources)
No. Parameters
Test Conditions
Pin
Symbol
Min
Typ.
Max.
Unit
Type*
17.1 Output voltage (V1)
(x = 1 to 5),
–40 mA < I
IASGx
< –0.5 mA
V
ISENS
= 0.96
×
V
VPERI
IASG
x
V1
IASGx
–6%
10
+6%
V
A
17.2 Output voltage (V2)
(x = 1 to 5),
–40 mA < I
IASGx
< –0.5 mA
V
ISENS
= 0.96
×
V
VPERI
IASG
x
switched to 5V
V
EVZ
> 11V
IASG
x
V2
IASGx
–6%
5
+6%
V
A
17.2a Output voltage (V2)
(x = 1 to 5),
–25 mA < I
IASGx
< –0.5 mA
V
ISENS
= 0.96
×
V
VPERI
IASG
x
switched to 5V
V
EVZ
> 9V to 11V
IASG
x
V2
IASGx
–6%
5
+6%
V
A
17.3
Output voltage overshoot at
IASGx due to regulator
characteristic
(x = 1 to 5)
when IASG = 5V
when IASG = 10V
IASG
x
∆
V
IASGx
5.9
11.3
V
V
A
A
17.4
Maximum duration of voltage
overshoot at IASGx
(x = 1 to 5),
with V
IASGx
= 10V / 0.5 mA <
R
LOAD
< V
IASGx
= 5V / 40 mA
IASG
x
t
IASGx
30
µs
A
17.5
Linear range for current mirror
at IASGx
(x = 1 to 5),
0V = V
ISENS
= 0.96
×
V
PERI
IASG
x
I
IASGx
–40
–0.5
mA
A
17.6
Internal current limitation at
IASG
x
(x = 1 to 5)
IASG
x
I
IASGx
–150
–50
mA
A
17.7 Current ratio #1
(x = 1 to 5),
CR
1x
= I
IASGx
/ I
ISENS
0V = V
ISENS
= 0.96
×
V
VPERI
–40 mA < I
IASGx
< –0.5mA
IASG
x
CR
1x
–3%
9.9
+3%
A
17.8 Current ratio #2
(x = 1 to 5),
CR
2x
= I
IASGx
/ I
ISENS
0V = V
ISENS
= 0.96
×
V
VPERI
–40 mA < I
IASGx
< –0.5 mA
IASG
x
CR
2x
–3%
14.9
+3%
A
17.9 Settling time
(x = 1 to 5),
R
IASGx
= 250
Ω
, no capacitive
load at IASGx
ISENSE
t
ISENSE
0
50
µs
A
17.10 Switch-on delay
(x = 1 to 5)
Measured from rising edge
of SSQ to
V
IASGx
= 0.1
×
V
IASGx
R
IASGx
= 250
Ω
, no
capacitive load at IASGx
IASG
x
t
IASGx
0
50
µs
A
*) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
