Test 2-3: DC Offset (cont’d)
Test Procedure
(cont’d)
Perform steps 5 - 7 for each offset listed in Table 2-3:
5. If necessary, change the AFG output amplitude:
VOLT:OFFS 0; Set offset to 0
:VOLT Set amplitude
where is the value specified in Table 2-3.
6. Set AFG offset voltage:
VOLT:OFFS Set offset
where is the value specified in Table 2-3.
7. Trigger the DMM and record the reading.
Table 2-3. DC Offset Test Points
Offset
(volts)
Amplitude
(volts)
Test Limits
(volts)
9.755
4.000
-4.000
-9.755
2.000
-2.000
2.29189
2.29189
2.29189
2.29189
0.40756
0.40756 9.755
±
0.1196
4.0
±
0.0620
-4.0
±
0.0620
-9.755 ± 0.1196
2.0
±
0.0244
-2.0 ± 0.0244
42 Verification Tests Agilent E1445A Service Manual
