Recommended
Test Equipment
Table 1-1 lists the test equipment recommended for testing, adjusting, and
servicing the AFG. Essential requirements for each piece of test equipment
are described in the Requirements column.
Table 1-1. Recommended Test Equipment
Instrument Requirements Recommended
Model
Use*
Controller, GP-IB GP-IB compatibility as defined by IEEE
Standard 488-1988 and the identical
ANSI Standard MC1.1: SH1, AH1, T2,
TE0, L2, LE0, SR0, RL0, PP0, DC0,
DT0, and C1, 2, 3, 4, 5. HP 9000 Series 300
or
IBM Compatible PC
with HP BASIC F,O,P,
A,T
Mainframe Compatible with AFG Agilent E1401B/T or
E1421B F,O,P,
A,T
Command Module 10 MHz Clk Out
TTL compatible Trig Out Agilent E1405B or
Agilent E1406A F,O,P,
A,T
Digital Multimeter DCV, ACV, 4-wire ohms w/offset comp Agilent 3458A O,P,A
Power Meter Frequency Range: 400 kHz - 10.8 MHz Agilent 8902A O,P,A
Power Sensor Frequency Range: 400 kHz - 10.8 MHz Agilent 11722A O,P,A
Counter Frequency Range: 100 Hz - 45 MHz Agilent 5334A/B O,P
Spectrum Analyzer Frequency Range: 100 kHz - 150 MHz Agilent 8566B O,P,A
Oscilloscope General Purpose
Bandwidth: 20 MHz Agilent 54111D F
50
Ω
feed-thru
termination
50
±
0.10
Ω Agilent 11048C O,P,A
* F = Functional Verification, O = Operation Verification Tests, P = Performance Verification
Tests, A = Adjustments, T = Troubleshooting
Agilent E1445A Service Manual General Information 15
