Main Screen (both pumps in dispense mode): Speed/Strokes

adjust via keypad

Press the up/down

arrow keys then

the enter

key to adjust the desired pump

Speed can be adjusted based on the control type selected from the Input Setup section in the

manual. By default the PDS-100 is configured for Keypad Control and Keypad Start.

To adjust the speed press the up arrow

key and then press the enter

key. Press the

up/down

arrow keys to adjust and then press the enter

key when finished to save.

To adjust the number of strokes press the down

arrow and then press the enter

key.

Press the up/down

arrow keys to adjust and then press the enter

key when

finished to save. Press the enter

key one final time to go back to the main screen.

Duo Mode

USE ARROWS TO SELECT

A = Dispense
B = Dispense

PRESS ‘ENTER’ TO ADJUST

A=Dispense

USE ENTER WHEN FINISHED

Speed = 200 rpm

Strokes = 10

USE ARROWS TO ADJUST
