Setup Screens (two individually controlled pumps) cont’d:
Prime/Purge adjust and activation
Prime and Purge have the following available settings.
***Factory default values shown***
Speed (7 – 749 RPM for the STH & RH and 7 – 599 RPM for the STQ &
STQP)
Run
1. Run = “Start&Stop”. Start prime/purge via keypad “Run” and
stop prime/purge via “Stop”
2. Run = “Ext. Switch”. Start prime/purge via external switch.
Pump will continue to prime/purge until switch is released.
Switch A activates pump A and Switch B activates pump B.
3. Run – “Start&Hold”. Start prime/purge via keypad “Run”.
Prime/purge will continue until the Run button is released.
To adjust either the speed or run method simply press the up or down arrow
keys to go to the desired item and then press the enter key to select. To set the
speed press the up/down arrow keys until the desired speed is shown. Press
enter key to save. To set the desired run method press the up/down
arrow keys until the desired run method is shown. Press enter key to save. To
start the Prime/Purge process use the device chosen (Keypad run button or external
switch). To exit setup press the setup
key and the motor(s) will automatically home
or press the enter key to go to the next setup screen.
Setup A = Prime
‘ENTER’ FOR NEXT MENU
Speed = 200 rpm
Run = Start&Stop
USE ARROWS TO SELECT
Setup A = Purge
‘ENTER’ FOR NEXT MENU
Speed = 200 rpm
Run = Start&Stop
USE ARROWS TO SELECT
