Configuration Modes Screens
(Appears when Up Arrow and setup Keys are held down while powering up unit)
The unit comes pre-configured as a Dual Individual system when purchased as a dual pump
system. To configure the dual pump system for “In Phase” operation or “Out Phase” operation
follow the procedure mentioned above to modify. If the unit supplied is a single pump system
there is no need to change the configuration.
Possible drive configurations types supported (configured by factory):
1. Single: Single pump.
* 2. I ndividual: Two pumps that can be controlled independently
3. In Phase: Two pumps that are in phase with each other.
4. Out of Phase: Two pumps that run 180 degrees out of phase for each other.
5. Smooth: Requires factory calibrated pump drive assembly.
Not covered in this
manual.
* Default Setting
The following screens will be seen when entering the configuration mode. The configuration
mode can only be entered if the up
arrow key and setup keys are held down while
powering on the unit. After configuration selection is made, power down and then restart the unit
for changes to take effect.
PDS-100
Configuration
Setup
Software
Version
Setup = Mode
‘ENTER’ FOR NEXT MENU
Pump = RH
Drive = Out Phase
USE ARROWS TO SELECT
