RS485 Connector Pin, command set and specifications (cont’d)
Note: PDS-100 accommodates up to 31 addressable units.
Command Mapping
Single bit read and write. Set bit to initiate action, PDS-100 will clear bit upon execution
Coil 0 = "start" > Pump A – (all configurations except individual – individual pump A only)
Coil 1 = "stop" > Pump A – (all configurations except individual – individual pump A only)
Coil 2 = “start-2" > Pump B – (individual configuration only)
Coil 3 = "stop-2" > Pump B – (individual configuration only)
Single bit status, read only
Input 0 = "busy" > Pump A – (all configurations except individual – individual pump A only)
Input 1 = "error” > Pump A – (all configurations except individual – individual pump A only)
Input 2 = "busy-2" > Pump B – (individual configuration only)
Input 3 = "error-2" > Pump B – (individual configuration only)
16 bit word read and write. Not allowed to change when pump is busy
Holding Register 0 = "rpm" > Pump A
Holding Register 1 = "stroke count" > Pump A
Holding Register 2 = "rpm-2" > Pump B
Holding Register 3 = "stroke count-2" > Pump B
16 bit word information read only
Input Register 0 = "configuration" *see configuration table
Input Register 1 = "operating mode" 0=continuous, 1=dispense
Input Register 2 = "operating mode-2" 0=continuous, 1=dispense
Input Register 3 = "error code" 0= no error, 1= error
Input Register 4 = "error code-2" 0= no error, 1= error
Input Register 5 = "minimum-speed"
Input Register 6 = "maximum-speed"
DRIVE CODE
Single (RH) 16384
Single (STH) 16385
Single (STQ) 16386
Single (STQP) 16387
Individual (RH) 49152
Individual (STH) 49153
Individual (STQ) 49154
Individual (STQP) 49155
In phase (RH) 49664
In phase (STH) 49665
In phase (STQ) 49666
In phase (STQP) 49667
Out of phase (RH) 50688
Out of phase (STH) 50689
Out of phase (STQ) 50690
Out of phase (STQP) 50691
Smooth (RH) 52736
Smooth (STH) 52737
Smooth (STQ) 52738
Smooth (STQP) 52739
Configuration Table
IN-PDS100-13A
11/1/13 HW
