CDB5484U_REV_C.PL BILL OF MATERIAL
Item Cirrus P/N Rev Description Qty Reference Designator MFG MFG P/N Notes Status
36 020-01816-Z1 A RES 1k OHM 1/8W ±1% NPb 0805 FILM 0 R9 R13 R23 R24 DALE CRCW08051K00FKEA NO POP A
37 021-00347-Z1 A RES 2.2 OHM 1/8W ±5% NPb 0805 FILM 0 R11 DALE CRCW08052R20JNEA NO POP A
38 021-01445-Z1 A RES 2.2 OHM 1/10W ±5% NPb 0603 0 R20 DALE CRCW06032R20JNEA NO POP A
39 021-00407-Z1 A RES 680 OHM 1/8W ±5% NPb 0805 FILM 5 R25 R26 R27 R28 R48 DALE CRCW0805680RJNEA A
40 021-00238-Z1 A RES 680 OHM 1/10W ±5% NPb 0603 FILM 2 R29 R32 KOA RK73B1JTTD681J A
41 021-00259-Z1 A RES 5.1k OHM 1/10W ±5% NPb 0603 FIL 3 R30 R31 R47 DALE CRCW06035K10JNEA A
42 021-00266-Z1 A RES 10k OHM 1/10W ±5% NPb 0603 FILM 1 R33 DALE CRCW060310K0JNEA A
43 020-00673-Z1 A RES 0 OHM 1/10W ±5% NPb 0603 FILM 10 R34 R35 R36 R37 R38 R39 R40 R41 R42 R43 DALE CRCW06030000Z0EA A
44 021-00242-Z1 A RES 1k OHM 1/10W ±5% NPb 0603 FILM 3 R44 R45 R46 DALE CRCW06031K00JNEA A
45 020-01473-Z1 A RES 0 OHM 1/18W ±1% NPb 0805 FILM 2 R51 R54 DALE CRCW08050000Z0EA A
46 020-00914-Z1 A RES 130 OHM 1/10W ±1% NPb 0603 FILM 1 R55 DALE CRCW0603130RFKEA A
47 020-00673-Z1 A RES 0 OHM 1/10W ±5% NPb 0603 FILM 0 R56 DALE CRCW06030000Z0EA NO POP A
48 021-00718-Z1 A RES 20 OHM 1/3W ±5% NPb 1210 FILM 1 R57 DALE CRCW121020R0JNEA A
49 120-00002-Z1 A SWT SPST 130G 0/1 5mm TACT ESD NPb 2 S1 S2 ITT INDUSTRIES PTS645TL50 LFS INSTALL AFTER WASH PROCESS A
50 110-00045-Z1 A CON TEST PT .1"CTR TIN PLAT NPb BLK 10 TP1 TP2 TP3 TP4 TP5 TP6 TP7 TP8 TP9 TP10 KEYSTONE 5001 A
51 065-00332-Z4 B2 IC CRUS BIDIR ENER MEAS NPb QFN28L 1 U1 CIRRUS LOGIC CS5484-INZ/B2 ECO899, ECO935 A
52 060-00568-Z1 A IC ISOL 5CH 2.5kV 5/0 NPb SOIC16N 1 U2 SILICON LABORATORIES Si8450BB-B-IS1
A
53 060-00567-Z1 A IC ISOL 5CH 2.5kV 4/1 NPb SOIC16N 1 U3 SILICON LABORATORIES Si8451BB-B-IS1
A
54 175-00031-Z1 A OPT COUP TRANS 50-600% NPb DIP4 2 U4 U5 TOSHIBA TLP781(F) A
55 062-00229-Z1 A IC PGM USB 64kB FLAS MCU NPb LQFP32 1 U6 SILICON LABORATORIES
INC C8051F342-GQ PROGRAM AT TEST
A
56 160-00012-Z1 A LCD MODULE 3.3V 16x2 16x64mm NPb 1 U7 TOPWAY LMB162AFC-2 NEED HDR16X1-SSW-116-01-G-S, TSW-
116-07-G-S, #2 STANDOFF .500
LENGTH, SCREWS
A
57 061-00392-Z1 A IC DIG DC/DC CONV 5V 1W NPb SMD8 1 U8 V-INFINITY VBT1-S5-S5-SMT A
58 060-00319-Z1 A IC LNR VREG μPWR 150mA NPb SOT23-5 1 U9 NATIONAL
SEMICONDUCTOR LP2985IM5-3.3/NOPB
A
59 100-00120-Z1 A XTL 4.096MHZ HC49US 30ppm 20pF NPb 1 Y1 ECS ECS-41-20-4X INSTALL PIN SOCKETS A
60 070-00006-Z1 A DIODE TR 6.8V 600W NPb AXL 2 Z1 Z2 LITTELFUSE P6KE6.8 A
61 070-00200-Z1 A DIODE TVS 3.3V 2LN ESD NPb SOT23 1 Z3 COMCHIP TECHNOLOGY CTES033V3-G ECO852
A
62 603-00478-Z1 C ASSY DWG CDB5484U-Z-NPb REF CIRRUS LOGIC 603-00478-Z1 ECO852
63 240-00478-Z1 C PCB CDB5484U-Z-NPb 1 CIRRUS LOGIC 240-00478-Z1 ECO852 A
64 600-00478-Z1 C2 SCHEM CDB5484U-Z NPb REF CIRRUS LOGIC 600-00478-Z1 ECO852, ECO899, ECO935 A
65 422-00013-Z1 D LBL SUBASSY PRODUCT ID AND REV 1 CIRRUS LOGIC 422-00013-01 A
66 080-00003-Z1 A WIRE BPOST 1.5X.25 24/19 GA BLU NPb 2 XJ36 XJ37 SQUIRES L-1.5X.25TX.25T_TYPE_E_ A
67 135-00003-Z1 A SKT 1P .100"L .041"DIA GLD NPb 2 XY1(2 PINS) AUGAT 8134-HC-5P2 A
68 300-00025-Z1 A SCREW 4-40X5/16" PH MACH SS NPb 7 XMH1 XMH2 XMH3 XMH4 XMH5 XMH6 XMH7 BUILDING FASTENERS PMSSS 440 0031 PH A
69 110-00013-Z1 D CON SHUNT 2P .1"CTR BLK NPb 36 MOLEX 15-29-1025 INSTALL AT TEST A
70 422-00180-Z1 A LBL RoHS 1 IMAGE-TEK LPP0054 PLACE LABEL ON THE SECONDARY
SIDE
A
Figure 33. Bill of Materials (Page 2 of 2)
