2.8.1.11 Histogram Information
The following is a description of the indicators associated with histogram analysis. Histograms can be plot-
ted in the Data Collection window by setting the analysis type pull-down menu to Histogram. See
Figure 27. The histogram plot information includes:
• BIN: Displays the x-axis value of the cursor on the histogram.
• MAGNITUDE: Displays the y-axis value of the cursor on the histogram.
• MEAN: Indicates the mean of the data sample set. The mean is calculated using the following
formula:
• STD_DEV: Indicates the standard deviation of the collected data set. The standard deviation is
calculated using the following formula:
• VARIANCE: Indicates the variance of the current data set. The variance is calculated using the
following formula:
• MAXIMUM: Indicates the maximum value of the collected data set.
• MINIMUM: Indicates the minimum value of the collected data set.
Mean
X
i
i 0 =
n 1 –

n
---------------------- =
STDDEV
Xi Mean –  
i 0 =
n 1 –

n
------------------------------------------------------
2
=
Variance
Xi Mean –  
i 0 =
n 1 –

n
------------------------------------------------------
2
=
