CS5480
DS980F3
37
6.6 Register Descriptions
22.
“Default” = bit states after power-on or reset
23.
DO NOT write a “1” to any unpublished register bit or to a bit published as “0”.
24.
DO NOT write a “0” to any bit published as “1”.
25.
DO NOT write to any unpublished register address.
6.6.1 Configuration 0 (Config0)
–
Page 0, Address 0
Default = 0xC0 2000
[23:9]
Reserved.
INT_POL
Interrupt Polarity.
0 = Active low (Default)
1 = Active high
I2PGA[1:0]
Select PGA gain for I2 channel.
00 = 10x gain (Default)
10 = 50x gain
I1PGA[1:0]
Select PGA gain for I1 channel.
00 = 10x gain (Default)
10 = 50x gain
[3]
Reserved.
NO_OSC
Disable crystal oscillator (making XIN a logic-level input).
0 = Crystal oscillator enabled (Default)
1 = Crystal oscillator disabled
IZX_CH
Select current channel for zero-cross detect.
0 = Selects current channel 1 for zero-cross detect (Default)
1 = Selects current channel 2 for zero-cross detect
[0]
Reserved.
23
22
21
20
19
18
17
16
1
1
0
0
-
-
-
-
15
14
13
12
11
10
9
8
-
0
1
0
0
-
-
INT_POL
7
6
5
4
3
2
1
0
I2PGA[1]
I2PGA[0]
I1PGA[1]
I1PGA[0]
-
NO_OSC
IZX_CH
-
