CS5480
DS980F3
35
6.4 Software Registers Summary (Page 17)
Address
2
RA[5:0]
Name
Description
1
DSP
3
HOST
3
Default
0*
00 0000
V1Sag
DUR
V1 Sag Duration
Y
Y
0x 00 0000
1*
00 0001
V1Sag
LEVEL
V1 Sag Level
Y
Y
0x 00 0000
2
00 0010
-
Reserved
-
3
00 0011
-
Reserved
-
4*
00 0100
I1Over
DUR
I1 Overcurrent Duration
Y
Y
0x 00 0000
5*
00 0101
I1Over
LEVEL
I1 Overcurrent Level
Y
Y
0x 7F FFFF
6
00 0110
-
Reserved
-
7
00 0111
-
Reserved
-
8*
00 1000
V2Sag
DUR
V2 Sag Duration
Y
Y
0x 00 0000
9*
00 1001
V2Sag
LEVEL
V2 Sag Level
Y
Y
0x 00 0000
10
00 1010
-
Reserved
-
11
00 1011
-
Reserved
-
12*
00 1100
I2Over
DUR
I2 Overcurrent Duration
Y
Y
0x 00 0000
13*
00 1101
I2Over
LEVEL
I2 Overcurrent Level
Y
Y
0x 7F FFFF
14
00 1110
-
Reserved
-
15
00 1111
-
Reserved
-
16
01 0000
-
Reserved
-
17
01 0001
-
Reserved
-
18
01 0010
-
Reserved
-
19
01 0011
-
Reserved
-
20
01 0100
-
Reserved
-
21
01 0101
-
Reserved
-
22
01 0110
-
Reserved
-
23
01 0111
-
Reserved
-
24
01 1000
-
Reserved
-
25
01 1001
-
Reserved
-
26
01 1010
-
Reserved
-
27
01 1011
-
Reserved
-
28
01 1100
-
Reserved
-
29
01 1101
-
Reserved
-
30
01 1110
-
Reserved
-
31
01 1111
-
Reserved
-
Notes: (1)
Warning:
Do not write to unpublished or reserved register locations.
(2) * Registers with checksum protection.
(3) Registers that can be set to write protect from DSP and/or HOST.
