CS5371A CS5372A
DS748F3 7
PERFORMANCE CHARACTERISTICS (CONT.)
Notes: 16. Specification is for the parameter over the specified temperature range and is for the device only. It does
not include the effects of external components.
17. Specification applies to the effective offset voltage calculated from the output codes of the digital filter
following offset calibration and correction.
18. Offset calibration is performed in the digital filter and includes the full-scale signal range.
Parameter Symbol Min Typ Max Unit
Gain Accuracy
Channel to Channel Gain Accuracy ( Note 3 ) GA - ±1 ±2 %
Channel Gain Drift ( Note 16 ) GA
TC
- 22 - ppm/°C
Offset
Offset Voltage, Differential (OFST = 0) OFST - ±1 - mV
Offset Voltage, CS5371A (OFST = 1) OFST - -60 - mV
Offset Voltage, CS5372A channel 1 (OFST = 1) OFST - -60 - mV
Offset Voltage, CS5372A channel 2 (OFST = 1) OFST - -35 - mV
Offset after Calibration ( Note 17 ) OFST
CAL
- ±1 - μV
Offset Calibration Range ( Note 18 ) OFST
RNG
- 100 - %FS
Offset Voltage Drift ( Note 16 ) OFST
TC
- 300 - nV/°C
