CS5371A CS5372A
6 DS748F3
PERFORMANCE CHARACTERISTICS
Notes: 9. Guaranteed by design and/or characterization.
10. The upper bandwidth limit is determined by the digital filter cut-off frequency.
11. Common mode voltage is defined as the mid-point of the differential signal.
12. Dynamic Range defined as 20 log [ (RMS full scale) / (RMS idle noise) ] where idle noise is measured
from a CS3301A / CS3302A amplifier terminated input at 1x gain.
13. Signal-dependent Noise defined as 20 log [ (RMS full scale) / (RMS signal noise) ] where signal noise
is measured by subtracting out the signal power at the fundamental and harmonic frequencies.
14. Tested with a 31.25 Hz sine wave at -1 dB amplitude and Vcm = (VA-) + 2.50V.
15. Characterized with a 31.25 Hz sine wave at -1 dB amplitude and Vcm = (VA-) + 2.35V. This
corresponds to the output Vcm of the CS4373A test DAC.
Parameter Symbol Min Typ Max Unit
Signal Characteristics
Input Signal Frequencies ( Note 9, 10) V
BW
DC - 2000 Hz
Full-scale Differential AC Input ( Note 9 ) V
AC
- - 5 V
pp
Full-scale Differential DC Input ( Note 9 ) V
DC
-2.5 - 2.5 V
Input Common Mode Voltage ( Note 11) V
CM
- (VA-)+2.5 - V
Input Voltage Range (V
cm
± Signal ) ( Note 9) V
RNG
(VA-)+0.7 - (VA+)-1.25 V
Dynamic Performance
Dynamic Range (1/4 ms) DC to 1720 Hz
( Note 10, 12 ) (1/2 ms) DC to 860 Hz
(1 ms) DC to 430 Hz
(2 ms) DC to 215 Hz
(4 ms) DC to 108 Hz
(8 ms) DC to
54 Hz
(16 ms) DC to 27 Hz
SNR -
-
121
-
-
-
-
109
121
124
127
130
133
136 -
-
-
-
-
-
- dB
dB
dB
dB
dB
dB
dB
Signal-dependent Noise (1 ms) DC to 430 Hz
( Note 13, 14 )
SDN 100 110 - dB
Total Harmonic Distortion ( Note 14 ) THD - -118 -112 dB
Linearity ( Note 14 ) LIN - 0.000126 0.000251 %
Total Harmonic Distortion ( Note 15 ) THD - -110 - dB
Linearity ( Note 15 ) LIN - 0.000316 - %
Common Mode Rejection Ratio CMRR - 110 - dB
Channel Crosstalk (CS5372A only) CXT - -150 - dB
