CS5371A CS5372A
10 DS748F3
DIGITAL CHARACTERISTICS (CONT.)
Notes: 20. MCLK is generated by the digital filter. If MCLK is disabled, the device automatically enters a power-
down state.
21. MSYNC is generated by the digital filter and is latched on MCLK falling edge, synchronization instant
(t
0
) is on the next MCLK rising edge.
22. Decimated, filtered, and offset-corrected 24-bit output word from the digital filter.
Parameter Symbol Min Typ Max Unit
Master Clock Input
MCLK Frequency ( Note 20 ) f
CLK
- 2.048 - MHz
MCLK Period ( Note 20 ) t
mclk
- 488 - ns
MCLK Duty Cycle ( Note 9 ) MCLK
DC
40 - 60 %
MCLK Rise Time ( Note 9 ) t
RISE
- - 50 ns
MCLK Fall Time ( Note 9 ) t
FALL
- - 50 ns
MCLK Jitter (in-band or aliased in-band) ( Note 9 ) MCLK
IBJ
- - 300 ps
MCLK Jitter (out-of-band) ( Note 9 ) MCLK
OBJ
- - 1 ns
Master Sync Input
MSYNC Setup Time to MCLK Falling ( Note 9, 21 ) t
mss
20 122 - ns
MSYNC Period ( Note 9, 21 ) t
msync
40 976 - ns
MSYNC Hold Time after MCLK Falling ( Note 9, 21 ) t
msh
20 122 - ns
MDATA Output
MDATA Output Bit Rate f
mdata
- 512 - kbits/s
MDATA Output Bit Period t
mdata
- 1953 - ns
MDATA Output One’s Density Range ( Note 9 ) MDAT
OD
14 - 86 %
Full-scale Output Code ( Note 22 ) MDAT
FS
0xA2EBE0 - 0x5D1420
