CS5371A CS5372A
4 DS748F3
1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the Specified Operating Conditions .
• Typical performance characteristics and specifications are measured at nominal supply voltages and T
A
= 25 °C.
• GND = 0 V. Single-ended voltages with respect to GND, differential voltages with respect to opposite half.
• Device is connected as shown in Figure 9 on page 13 unless otherwise noted.
SPECIFIED OPERATING CONDITIONS
Notes: 1. VA- must always be the most-negative input voltage to avoid potential SCR latch-up conditions.
2. By design, a 2.500 V voltage reference input results in the best signal-to-noise performance.
3. Channel-to-channel gain accuracy is directly proportional to the voltage reference absolute accuracy.
4. VREF inputs must satisfy: VA-
≤ VREF- < VREF+ ≤ VA+.
ABSOLUTE MAXIMUM RATINGS
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Notes: 5. Transient currents up to ±100 mA will not cause SCR latch-up.
6. Includes continuous over-voltage conditions at the modulator analog input pins.
Parameter Symbol Min Nom Max Unit
Bipolar Power Supplies
Positive Analog ± 2% VA+ 2.45 2.50 2.55 V
Negative Analog ( Note 1 ) ± 2% VA- -2.45 -2.50 -2.55 V
Positive Digital ± 3% VD 3.20 3.30 3.40 V
Voltage Reference
[VREF+] - [VREF-] ( Note 2, 3 ) VREF - 2.500 - V
VREF- ( Note 4 ) VREF- - VA - - V
Thermal
Ambient Operating Temperature Industrial (-ISZ) T
A
-40 25 85 °C
Parameter Symbol Min Max Parameter
DC Power Supplies Positive Analog
Negative Analog
Digital
VA+
VA-
VD
-0.5
-6.8
-0.5 6.8
0.5
6.8 V
V
V
Analog Supply Differential (VA+) - (VA-) VA
DIFF
- 6.8 V
Digital Supply Differential (VD) - (VA-) VD
DIFF
- 6.8 V
Input Current, Power Supplies ( Note 5 ) I
PWR
- ±50 mA
Input Current, Any Pin Except Supplies ( Note 5, 6 ) I
IN
- ±10 mA
Output Current ( Note 5 ) I
OUT
- ±25 mA
Power Dissipation PDN - 500 mW
Analog Input Voltages V
INA
(VA-) - 0.5 (VA+) + 0.5 V
Digital Input Voltages V
IND
-0.5 (VD) + 0.5 V
Storage Temperature Range T
STG
-65 150 ºC
