D
S
73
4U
M
7
C
o
pyr
igh
t 20
09
C
irrus
Lo
gi
c, I
n
c
.
3
-12
Se
rial Co
ntrol Po
rt
Config
uratio
n
C
S
485
xx
H
a
rd
w
a
re
U
s
er
’s
Ma
nua
l
Figure 3-10. Sample Waveform for I
2
C Write Functional TIming
Note: The I
2
C slave is always responsible for driving the ACK for the address byte.
Figure 3-11. Sample Waveform for I
2
C Read Functional Timing
Notes: 1.The I
2
C slave is drives the ACK for the address byte.
2.The I
2
C master is responsible for controlling ACK during I
2
C reads. In general, the receiver in an I
2
C transaction is responsible for
providing ACK.
3.SCP_IRQ remains low until the rising edge of the clock for the last bit of the last byte read from the I
2
C slave.
4.A NACK is sent by the master after the last byte to indicate the end of the read cycle. This must be followed with an I
2
C Stop condition or
I
2
C Repeated-Start condition.
Start
SCP_CLK
SCP_SDA Data Byte 3 (MSB)
Stop
7-bit Address
R/
W
A
C
K
A
CK
Data Byte 2
A
C
K Data Byte 1
A
C
K Data Byte 0 (LSB)
AC
K
M S M S M S M S M S M
Start
SCP_CLK
SCP_SDA Data Byte 3 (MSB)
Stop
7-bit Address
R/
W
AC
K
AC
K Data Byte 2
AC
K Data Byte 1
AC
K Data Byte 0 (LSB)
SCP_IRQ
N
ACK
M S S M S M S M S M M
M = Master Drives SDA
S = Slave Drives SDA
