CDB47xxx Kit Contents
CDB47xxx User’s Manual
DS886DB11 Copyright 2014 Cirrus Logic, Inc 1-1
Chapter 1
Kit Contents and Requirements
1.1 CDB47xxx Kit Contents
Each CDB47xxx kit comes with the items listed in Table 1-1 .
Figure 1-1 and Figure 1-2 show the kit contents for the CDB47xxxS-DCxx (Single-ended) and
CDB47xxxD-DCxx (Differential) development boards respectivel y.
Table 1-1. CDB47xxx Kit Contents
CRD Kit Item Quantity
CDB47xxxS-DC48
CDB47xxxS-DC28
CDB47xxxS-DC24
CDB47xxxS Single-Ended Development Board with integrated MCU & USB interface
with daughtercard populated with either the CS47048, CS4028, or CS47024 DSP.
1
CDB47xxxD-DC48
CDB47xxxD-DC28
CDB47xxxD-DC24
CDB47xxxD Differential Development Board with integrated MCU & USB interface
with daughtercard populated with either the CS47048, CS4028, or CS47024 DSP.
1
CDB47xxxS-DCxx
CDB47xxxD-DCxx
Power Supply: +9V, 2A, 100V - 240V with AC Power Cord 1
CDB47xxxS-DCxx
CDB47xxxD-DCxx
USB Cable 1
CDB47xxxS-DCxx
CDB47xxxD-DCxx
Document Card explaining how to get the latest board software 1
