4-7 Copyright 2014 Cirrus Logic, Inc. DS886DB11
Running the ADC In / DAC Out Example Application
CDB47xxx User’s Manual
4.2.5 Selecting the Audio Output Configuration
Configure the audio outputs to the DSP by dragging and dropping the Audio Out block onto the
workspace. The dialog box shown in
Figure 4-8 appears. Choose from one of the supported output
combinations as described in the subsections, Section 4.2.5.1 to Section 4.2.5.3 . DAC is selected by
default. The input configuration may be changed later by right clicking on the Audio Out block and
selecting Device Properties.
The Device Properties dialog box allows the user to configure one or more of the following:
• DAC
• I
2
S
• S/PDIF Out
