Requirements
CDB47xxx User’s Manual
1.2 Requirements
1.2.1 PC Requirements
•
Microsoft
®
Windows
®
XP
with Service Pack 2 or higher or Windows 7 (32– or 64–bit) Operating
System
•
USB 2.0 Support
1.2.2 Software Requirements
•
Cirrus
®
Evaluation Software Package (available from your local Cirrus Logic representative)
1.2.3 Support Hardware Requirements
•
Digital or Analog Audio Source (for example, DVD player, PC with a digital audio card/device)
•
Amplified Speakers for audio playback (for example, powered PC speakers, AVR/amp + speakers)
1.2.4 Cabling Requirements
•
Digital Audio Inputs – S/PDIF optical cables, RCA audio cables (Connect to digital audio card, audio
analyzer, or DVD player.)
•
Digital Audio Output – S/PDIF Optical cable, RCA audio cable (Connect to digital audio card, audio
analyzer, or AVR.)
•
Analog Audio Inputs – 1/8” stereo plug microphone cable (Connect microphone to ADC), RCA audio
cables (CDB47xxxS only), 1/8” stereo plug differential cable (CDB47xxxD only)
•
Analog Audio Outputs – RCA audio cables (Connect CDB47xxx line-level outputs to powered
speakers.)
